Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices. The APC Smart-UPS 1000VA LCD 230V (SMT1000IC) is an intelligent and efficient network power protection solution, ideal for servers, point-of-sale systems, routers, switches, hubs, and other network devices. With its line-interactive topology, this UPS ensures that your equipment remains protected and operational even during power disturbances.

Key Features:

• Output Power Capacity: 700 Watts / 1.0 kVA
• Output Connections: 8x IEC 320 C13 (Battery Backup), 2x IEC Jumpers (Battery Backup)
• Nominal Output Voltage: 230V
• Nominal Input Voltage: 230V
• Input Connections: IEC 320 C14
• Smart Connect Port: Provides remote monitoring with automatic notifications, firmware updates, and advanced support services.
• LCD Interface: Intuitive interface with clear, accurate information and easy-to-use navigation keys for local configuration.

Protection & Performance:

• Cold-start Capable: Provides temporary battery power when utility power is out.
• Energy Meter: Tracks actual kilowatt hours of usage for energy-conscious users.
• Green Mode: Bypasses unused electrical components during good power conditions to achieve high efficiency without sacrificing protection.
• High Online Efficiency: Reduces utility costs and generates less heat.
• Intelligent Card Slot: Allows customization of UPS capabilities with management cards.
• Predictive Replace Battery Date: Indicates the recommended month and year for battery replacement to aid in long-term maintenance planning.
• Pure Sine Wave Output on Battery: Ensures the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
• Single Switched Outlet Group: Allows for discrete reboot of hung devices, sequenced on/off, and non-critical load shedding.

Technical Specifications:

• Max Configurable Power: 700 Watts / 1.0 kVA
• Output Voltage Distortion: Less than 5%
• Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz
• Waveform Type: Sine wave
• Transfer Time: 6 ms typical, 10 ms maximum
• Input Voltage Range: 151 – 302V Adjustable, 160 – 286V
• Battery Type: Lead-acid battery
• Typical Recharge Time: 3 hours
• Replacement Battery: RBC6
• Expected Battery Life: 3 – 5 years
• Surge Energy Rating: 459 Joules

Physical Specifications:

• Dimensions (H x W x D): 219mm x 171mm x 439mm
• Net Weight: 19.4 kg
• Shipping Weight: 22.77 kg
• Color: Black

Environmental Specifications:

• Operating Temperature: 0 – 40°C
• Operating Relative Humidity: 0 – 95%
• Operating Elevation: 0 – 3048 meters
• Storage Temperature: -15 – 45°C
• Storage Relative Humidity: 0 – 95%
• Storage Elevation: 0 – 15240 meters
• Audible Noise: 41.0 dBA at 1 meter from the surface of the unit
• Online Thermal Dissipation: 100 BTU/hr

Conformance:

• Approvals: CE, EAC, RCM, UK PSTI, VDE

Included Accessories:

• Cat 5 Ethernet cable
• Installation guide
• USB cable

The APC Smart-UPS 1000VA LCD 230V is designed to provide reliable power protection with advanced features to enhance your network’s efficiency and manageability.
