Entrance & Exit Controllers – DS-TMT201-D
Entrance Ticket Station
- 10.1 inch wide temperature high brightness LCD screen, support text, two-dimensional code and other information display, support picture, video loop playback
- Device integrated IC card reader, support card upload
- The device contains 1 relay-out interface, which can be used for remote control barrier
- Support real-time voice intercom function, Integrated echo cancellation and noise cancellation technology
- Increase the paper damping to prevent the paper from falling off
- roll paper diameter up to 15cm, can be used for a longer time
- the maximum thickness of the paper can be 120g/1㎡, thicker and harder, to ensure that the printing receipt is maintained for a longer time
KSh 400,000.00 plus 16% VAT
DS-TMT201-D Dual-Lane Entrance & Exit Ticket Controller – Intelligent Vehicle Access Management
Description:
Streamline your vehicle entry and exit processes with the DS-TMT201-D Entrance & Exit Controller, an intelligent dual-lane ticket control system from Hikvision. Designed for high-traffic environments like parking lots, toll booths, and automated gates, this controller ensures reliable ticket issuing, user-friendly operation, and seamless integration with access management solutions. Now available at GEMANI SUPPLIES, it offers the performance and reliability essential for modern traffic control.
Key Features:
-
Supports both entrance and exit ticket processing in one unit
-
Dual-lane support for increased traffic throughput
-
Compatible with thermal ticket printers
-
Multiple working modes: automatic/manual ticket issuance
-
Built-in voice prompts and LED indicators for user guidance
-
Seamless integration with vehicle detection loops and barriers
-
Remote device management and diagnostics
Specifications:
-
Model: DS-TMT201-D
-
Functionality: Dual-lane ticket control for entrance and exit
-
Printer Compatibility: Thermal (e.g., DS-TMT002-P)
-
Communication Interface: RS-485 / TCP/IP
-
Audio: Built-in speaker for voice prompts
-
Indicators: LED status lights
-
Power Supply: 12V DC
-
Operating Temperature: -20°C to +60°C
-
Dimensions: Approx. 320mm × 240mm × 110mm
-
Use Case: Car parks, gated residential areas, commercial access points
| Brand | Hikvision |
|---|
