Hikvision DS-QAE0A60G1 Analog Amplifier 60W
Analog Amplifier 60W
- Rated Power: 60 W, 2 Zones
- Audio input: USB/Bluetooth/MIC/RCA
- Support two-zone volume adjustment
- Support four types of audio input: Bluetooth, USB flash drive, microphone, and RCA, with flexible and convenient operation
- Built-in Bluetooth module, support fast Bluetooth playback
- Support plugging in the USB flash drive to play audio sources
- Support independent microphone volume control and two-channel partition volume control
- Support two-channel audio mixing output
- Adopt high-strength engineering plastics, sturdy and durable
- Integrated functional design, convenient and reliable
KSh 13,000.00 plus 16% VAT
Hikvision DS-QAE0A60G1 Analog Amplifier 60W
The Hikvision DS-QAE0A60G1 is a 60W analog amplifier designed for public address (PA) and background music systems, supporting both 70V/100V line and 4-16Ω low-impedance speaker configurations.
Specification |
|
| Function | |
| Protection Function | short circuit protection, overcurrent protection, over temperature protection,anti-static electricity protection, surge protection, electrical shock protection |
| Audio | |
| Rated Power | 60 W24 VDC |
| Frequency Response | USB, Bluetooth: 20 Hz to 20 kHzMIC, RCA Input: 20 Hz to 8 kHz |
| THD and SNR | THD: ≤1%SNR: ≥100 dB |
Interface |
|
| Audio In | MIC 1: -20 dBV, 4 KΩ,unbalance, 6.35 mm jackUSB 2.0 × 1RCA in 1: 0 dBV, 5 KΩ, unbalance, RCA pin jack Bluetooth |
|
Audio Out |
Constant Voltage Output × 2，100 V COMConstant Resistance Output × 2，30 W 4 Ω to 8 Ω RCA Out 1: 0 dBV, 100 Ω, unbalance, RCA pin jack RCA Cascading: support a cascade of up to 3 amplifiersBluetooth |
| LED Indicator | Power indicator (solid white): the device is normally working USB flash drive indicator (solid white): the device is in USB mode Bluetooth indicator (solid blue): the device is in Bluetooth modeUSB flash drive indicator (off) and Bluetooth indicator (off): the MIC input and RCAinput are mixed |
| Volume Knob | MIC Volume Knob × 1，Partition 1 Volume Knob × 1，Partition 2 Volume Knob × 1 |
| USB | USB 2.0File format: FAT32USB flash drive file playing logic: traverse play level 3 directory files in the USB flash drive. |
| Power Interface | Aperture size: Ø2.0 mm |
General |
|
| Material | Plastic |
| Dimension | 190.8 mm × 230.8 mm × 51.2 mm (7.48″ × 9.06″ × 2.01″) |
| Package Dimension | 362 mm × 280 mm × 100 mm (14.25″ × 11.02″ × 3.94″) |
| Weight | Approx. 1445.5 g (3.19 lb.) |
| With Package Weight | Approx. 2113.3 g (4.66 lb.) |
| Color | White |
| Packing List | Device × 1Power Adapter × 1 Power Cord × 1Regulatory Compliance and Safety Information × 1 |
| Bluetooth | Bluetooth 5.3，10 m |
| Operating Temperature | -10 °C to 55 °C(14 °F to 131 °F) |
| Operating Humidity | ＜90% (No condensation) |
| Power Consumption | Standby Consumption: 1 WAnnual Average Consumption: Max. Working Consumption: 60 W (based on the average playing time) |
| Brand | Hikvision |
|---|
